Interior Folding: Multifold 30 For Top Hung Interior Folding Partitions. Max 30kg Each Door

Multifold 30

Application:

Multifold 30 is an interior folding door hardware system suitable for residential and light commercial folding partitions, cupboards and wardrobes. Panels can be either end folding or centre folding and weigh up to 30kg. The pivot hardware allows equal width doors to end fold in units of two, four or six panels on either side of the opening. Centre folding units consist of either one, three or five full width panels and one half width panel. Multifold 30 is available in convenient standard sets to suit a wide variety of door configurations.

Panel Specification:

Max Panel Weight: 30kg
Max Panel Width: 650mm
Max Panel Height: 2400mm
Min Panel Thickness: 19mm
Max Number of Panels: 6 each way

Note: MF30-APK is currently unavailable. Please order 1 hanger and 6 hinges as an alternative.

Bottom guide is required on 3 or more panels
